- 兰 州500w正弦波逆变器
详细信息
品牌：程浩 型号：CH-ZXB-500W 加工定制：是 电路拓扑结构：推挽式 输出电压波形：正弦波 输出电压范围：10.5-16 V 输出电压：220 V 逆变效率：95 % 电压调整率：5 % 负载调整率：5 % 产品认证：CE Product Name: 500W Pure Sine Wave Power Inverter
Country of Origin: China
Model: CH-ZXB-500W
Color: Silver /Black
Minimum order: 100 pieces
Delivery Lead Time: 25 Days
Delivery FOB port: China Ningbo port
Payment Condition: T/T
Detail Specifications
Continue Power:500 W Max. Output Surge: 1200 W DC Input Voltage: 12V or 24V or 36v or 48V AC Output Voltage: 110V or 120V or 220V or 230V or 240V
Dimensions (mm): (225+25) x 157 x 75 Weight (kg): 2.5 kg
?Output type:
Wired Remote Control Wireless Remote Control :
?Features :
l Dedicated design for the use of Solar Power Energy.
l Pure Sine Wave
l Wireless Remote Control and Wired Remote Control (Optional)
l Supply USB 5V/500mA
l High temperature alarm and protection system
l Output overloaded alarm and protection system
l Output short circuit alarm and protection system
l High surge capacity for starting demanding loads
l Alarm and protection for low / high battery
?Scope of Application :
Medical Instruments, Emergency Power, Oxygen Concentrators, Cash Register, Home Theater, High-end Stereos, Notebook, Computers, Power Tools, Radios, DVD players, TV s , Musical Instruments, Recording Equipments, Limousines, Buses, RV s, Precision Equipment, Sensitive Radio Equipment, Laser Printers, Fax Machines, etc. USB 5V DC output is for Digital Camera, Cell Phone, Video Game, MP3, MP4, PDA.
?YPS-600 Specifications:
Model
CH-ZXB-500W-12
CH-ZXB-500W-24
CH-ZXB-500W-
36
CH-ZXB-500W-48
Output
Continuous output
500W
Surge Power
1200W
AC Voltage
100V / 110V / 115V / 120V / 200V/ 220V / 230V / 240V to be selected
Regulation
Vrms ± 3%
Frequency
50Hz or 60Hz
Wave Form
Pure Sine Wave
Total Harmonic Distortion
THD＜3%
USB Output
DC 5V ± 5% 500mA
Input
BatteryVoltage
12V
24V
36V
48V
DC Current (typ.)
60A
30A
20A
15A
Low Battery Alarm
10.5V ± 2%
21V ± 2%
31.5V ± 2%
42V ± 2%
BatteryVoltage Low Stop
10V ± 2%
20V ± 2%
30V ± 2%
40V± 2%
High Battery
15V ± 2%
30V ± 2%
45V ± 2%
60V ± 2%
No load current
650mA
350mA
220mA
170mA
Efficiency
＞85%
Protection
High temperature
Yes
Short-circuit
Yes
Overload
Yes
Input Voltage
Yes
Intelligent Design Heat Auto Control
Fan Start : 42℃± 3 , Fan Stop : 38℃± 3
High Temperature Shut Down : 63℃±3 , Restart Output : 55℃±3
Indicator
Normally : Green LED Over Temperature: Yellow LEDExceptionally : Red LED
Others
Optional with wireless remote control or without remote control
Mechanical
Dimensions (mm)
225+25 (D) x 157 (W) x 75 (H)
Weight
2.5 kgs
-
-
